Motogadget m-Switch Push Button Housing

Motogadget m-Switch Push Button Housing

$ 99.00$ 118.00

The Motogadget m-Switch is the best option available for finalizing the switch gear on your custom project or just updating the controls on your machine. Designed to work perfectly with the Motogadget m-Unit, the m-Switch is available in 2-Button and 3-Button configurations to meet your projects needs. The m-Switch comes in black and polished finishes with the option to choose black or stainless push buttons in the housings. Analog stocks the 7/8″ m-Switch, but can special order 1″ if this is what you need.

If you’re looking for another Motogadget product that you’re unable to find listed here on our site, send us an email and we’ll be happy to special order any Motogadget components you need. Delivery time for special order products can vary, so please contact us with questions should your project be on a tight deadline.

Clear
Weight .2 lbs
Dimensions 3 × 3 × 3 in
Housing Style

2-Button, 3-Button

Housing Color

Black, Polished

Button Color

Black, Stainless

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

The Motogadget m-Switch is the best option available for finalizing the switch gear on your custom project or updating the controls on your machine. Designed to work perfectly with the Motogadget m-Unit, the m-Switch is available in 2-Button and 3-Button configurations to meet your projects needs. The m-Switch comes in black and polished finishes with the option to choose black or stainless push buttons in the housings. Analog stocks the 7/8″ m-Switch, but can special order 1″ if this is what you need.

For installation instructions, we encourage you to check out the m-Switch installation menu which can be found here.

For more information regarding the m-Switch, check out Motogadget’s product overview below:

The m-Switch is a high quality universal push-button control for handle bars with 1 in. or 22 mm (7/8 in.) tube diameter in a plain and elegant design.
These finely CNC machined hand controls in combination with an electronic push-button control unit (NOT INCLUDED IN KIT) are used to operate all electrical features, e.g. lights, turn signal, E-Starter, horn, etc.

The casing is made from CNC machined billet aluminium and available in mirror polished or reflective black finished surface respectively.
The compact design casing permits mounting two or more units on one handle bar.

Each unit is equipped with two or three push-buttons in black or stainless steel. Different looks matching or contrasting the casing can be combined freely.
Tw flush built-in M5 stainless steel mounting screws (only one screw on the three-button version) ensure secure and stable clamping of the push-button control to all handle bars.

The push-buttons are of high quality, very robust design and vibration- and spraywater-proof (IP65).
The adequate size and ergonomic pressure point (easy, mechanical detent) provide for a definite actuation sensing – even when operated with gloves. This feedback allows shifting without the need to check the operation.

Each push-button is equipped with two terminals for an easy optional circuit layout with only one or two cables. The internal ground terminal is already provided for the ‘one cable layout’. Therefore, the routing of the cable inside the handle bar can be performed easily.
The push-buttons are available separately and can be replaced if damaged.
The m-Switch is of course compatible to all common push-button controls, e.g. the m-Unit.

Dimensions
Inner diameter: 22 mm or 1 in.
Outer diameter: approx. 49 mm
Width: 20.5 mm
